Technical Specifications

General

Device Interfaces

• USB 2.0


• SIM slot (6-pin)


• microSD card slot (microSD card not included, supports up to 32 GB)

Broadband Wireless Support

• LTE/DC-HSPA+/HSPA/WCDMA


• GSM/GPRS/EDGE

Radio Frequency Bands

• LTE @ 2600/1800/800 Mhz


• UMTS @ 2100/900 Mh


• Quadband GSM/GPRS/EDGE

Data Rate¹

• LTE: 3GPP Rel-9 FDD-LTE Cat.4



  • Downlink: Up to 150 Mbps


  • Uplink: Up to 50 Mbps






• DC-HSPA+



  • Downlink: Up to 42 Mbps


  • Uplink: Up to 5.76 Mbps





Bandwidth

• 1.4, 3, 5, 10, 15, 20 MHz

Minimum System Requirements

• Windows XP/Vista/7/8/10, Mac OS X 10.5 or higher


• 128 MB RAM or greater


• 50 MB available disk space

Functionality

LTE Output Power

• Class 3 (23 dBm)

Antenna

• Integrated antenna

Status LED

• Green (blinking): Connected to LTE network


• Blue (blinking): Connected to 3G network


• Purple (blinking): Connected to 2G network


• Red (blinking): No service/device error

Plug and Play

• Built-in drivers and software; no CD-ROM required

Software Features

• Connection Manager



  • Phonebook


  • SMS messaging


  • APN Manager





Physical

Dimensions

• 103 x 34 x 11.5 mm (4.06 x 1.34 x 0.45 inches)

Weight

• 33 grams (1.16 ounces)

Certifications

• RoHS


• CE


• WHQL

¹ Data rates are theoretical. Data transfer rate depends on network capacity and signal strength. Please check regional mobile operators for 4G LTE/3G mobile Internet availability.

² Compatible with Windows XP/Vista/7/8, Mac OS X 10.5 or higher
